Sizes
SMB-55Dimension: Display Area: Package Size: | SMB-65Dimension: Display Area: Package Size: |
SMB-75Dimension: Display Area: Smartboard Size: 1707 x 1012.72 x 92 Package Size: | SMB-86Dimension: Display Area: Smartboard Size: Package Size: |
SMB-98Dimension: Display Area: Smartboard Size: 2216.8 x 1317.3 x 108.7 Package Size: | This file contains all the parameter data information of this series of standard models, does not represent all the parameter data of this series of products of our company, the actual parameter data should be subject to the specific model signed with the sales. |
Screens
Applicable to all sizes:
Screen Resolution: 3840 x 2160
Response Time: 6.5ms
Display Colors: 16.7 Billion
Brightness: 350cd/㎡
Viewing Angle: 178º
Touchscreen: 50 point
Protection: Anti-glare and screen protection
Power
Operating Voltage: 100V-240VAC, 50/60Hz
OPS
CPU | Intel Gen 4 i5 4210M |
Video Cards | Intel CPU Integrated Graphics |
Memory
| 8G DDR3 |
Storage | 128GB mSATA |
Network Card | Realtek 8111F Gigabit Network Card |
System | Windows 10 Pro/ Windows 11 |
Smartboard Pro Series
CPU | Intel 12th Gen i5-12450 |
Video Cards | Intel Iris Xe Graphics |
Memory
| 16GB DDR 4 SO-DIMM |
Storage | 256GB mSATA |
Network Card | Realtek 8111F Gigabit Network Card |
System | Windows 11 |
Android
CPU: 8x ARM Cortex-A55 1.2GHz
Android Version: 14.0
Memory: 4 GB
Storage capacity: 32 GB (expandable via SD card slot)
Smartboard Pro Series
CPU: Quadcore A55 CPU Mali G52 MP2
Android Version: 14.0
Memory: 8GB
Storage capacity: 128GB (expandable via SD card slot)
Additional Port: USB Type-C (Optional)
Camera
Image Sensor | HD CMOS Sensor |
Pixels | 13 Megapixels |
Lens Specification
| Wide-angle fixed focus |
Microphone
Audio Processor | Built-in microphone with quad-core digital processing chip |
8 Array Microphone | DSP core, supports 6 analog/digital MIC inputs, high performance echo cancellation (AEC) function |
Stereo Output
| High signal-to-noise ratio with low noise level 3uvrms, providing high-fidelity audio output |
Noise reduction | Enable |
Dynamic Compensation | 3D |
Ports
Smartboard Ports | |
HDMI | HDMI Port *2 |
USB | USB3.0 *2 + USB2.0 *2 |
RS232
| D-SUB *1 |
SD | 1 SD Card Slot (Expandable Storage) |
USB Type B | USB Type-B *1 |
OPS PC Ports | |
USB | USB3.0 *4 + USB2.0 *2 |
USB Type-C (Optional) | 1 USB Type-C for Pro Series Only |
LAN | LAN *1 |
HDMI | HDMI Port *1 |
Display Port | Display Port *1 |
Audio | Line *1 and Mic *1 |
Accessories
Touch Pen
Mobile Stand
Wall Mount
Remote
Power Cord
Warranty Card
Notice
All information contained in this document is subject to final interpretation by the Smartboard PH and all unauthorized and permitted reproduction is not approved and should be prohibited.
This file contains all the parameter data information of this series of standard models, does not represent all the parameter data of this series of products of our company, the actual parameter data should be subject to the specific model signed with the sales.
